| TECHNICAL SPECIFICATION |
| Model | WMM-50 | WMM-100 | WMM-150 |
| Output (TPH) | 50 | 100 | 150 |
| Cold Feed |
| Gathering Conveyor (mm.) | 600 | 600 | 600 |
| Belt Feeder Width (mm.) | 500 | 500 | 500 |
| No. of Bins | 4 | 4 | 4 |
| Bin Capacity (MT.) | 8 | 10 | 12 |
| Slinger Conveyor |
| Conveyor Width (mm.) | 600 | 600 | 600 |
| Pugmill |
| Capacity (cu. m.) | 1.4 | 1.6 | 1.9 |
| No. of Arms | 20 | 26 | 32 |
| Water Tank Capacity (MT.) | 15 | 15 | 20 |
| Mineral Filler Capacity (MT.) | 2 | 3 | 5 |
| Power Requirements |
| 4 Bin Feeder (HP) | 4 x 1.5 | 4 x 1.5 | 4 x 2.0 |
| Gathering Conveyor (HP) | 5 | 5 | 7.5 |
| Slinger Conveyor (HP) | 5 | 5 | 7.5 |
| Vibrating Screen (HP) | 0.5 | 0.5 | 0.5 |
| Pug Mill Drive (HP) | 15 | 25 | 50 |
| Hydraulic Power Pack (HP) | 3 | 3 | 3 |
| Water Pump (HP) | 2 | 3 | 5 |
| Blower (HP) | 2 | 2 | 3 |
